Back-to-back hook and loop cable ties replace single-use nylon zip ties wherever cables will be added, moved or serviced. The hook face grips the loop face at any point along the roll, so one roll covers every bundle diameter in the aisle instead of a drawer of fixed-length ties.
No adhesive, no residue. The tie closes on itself, so there is no glue line to fail and nothing to clean off rails, cable managers or equipment handles.
Re-openable without tools. A zip tie has to be cut; a hook and loop tie is peeled open and re-closed, which matters for moves, adds and changes.
Controlled compression. Tension is set by hand, so Cat6A and fibre bundles can be dressed without the over-tightening that affects insertion loss.
Soft woven edge. There is no sharp cut edge to abrade cable jackets during maintenance work.
Horizontal and vertical cable managers between patch panels and switches
Fibre trunk and MPO harness routing on the overhead tray
PDU and power cable bundling behind the rack
Colour-coded zone or tenant identification in black, white or custom colours
Cut length is driven by bundle circumference, not by rack width. For a bundle of diameter D, circumference is about 3.14 x D; add 30 to 50 mm for the overlap that carries the shear load.
| Bundle diameter | Circumference | Suggested cut length |
| 20 mm | about 63 mm | 120 mm |
| 40 mm | about 126 mm | 180 mm |
| 60 mm | about 188 mm | 250 mm |
| 80 mm | about 251 mm | 300 mm |
The figures above are calculated guidance only. All lengths from 8 to 1500 mm are made to order; as a rule of thumb, narrower rolls suit patch cords and single runs, wider rolls suit trunk bundles and overhead tray.
| Parameter | Value |
| Construction | Hook and loop laminated back to back with PUR glue |
| Substrate Thickness | 1.2mm ±0.1 |
| Size | 8-1500 mm, customized |
| Color | black, white, customized |
| Material | 100% Nylon / Nylon+Polyester (36 types of hook and loop can be free matching) |
| Shear strength | ≥11N/cm² |
| Packaging | 25 meters/roll or 27.5 yards/roll |
| MOQ | 100 Meters (Free Samples Available) |
For adhesive mounting without drilling, use adhesive-backed PP molded hook. For hot aisles or any area under a flammability review, use flame-retardant high-temperature hook and loop tape. Browse the full hook and loop product range, or ask about our converting service for pre-cut lengths and die-cut pads.
Does it leave adhesive residue on cables or rails? No. This construction is hook on one face and loop on the other, laminated with PUR glue, so the tie fastens to itself and never brings adhesive into contact with the equipment.
Can the same tie be re-used during a move? Yes, hook and loop is re-closable. Peel strength drops gradually with repeated opening, so keep spare roll length for bundles that are serviced often.
What is the minimum order? 100 meters, with free samples for evaluation before you commit to a rack build.
Can you supply pre-cut lengths or printed ties? Yes. The roll can be slit, cut, die-cut and printed; tell us your bundle range and quantity and we will quote against your BOM.
